● Type 2 cable/Type 2 socket
● APP Charging Scheduling
● Start Modes: RFlD/Plug&Play/APP
● CCID20 Residual Current Protection
● Multi communications(WiFi/4G/BLE)
● Charging Connector IP54,Host IP66/IK10
| PERFORMANCE SPECIFICATIONS | |
| Model | FF-AC3111USH-LJK |
| Standard | US |
| Power | 11.5KW |
| Input/Output Voltage | 208~240VAC/208~240VAC |
| Input Frequency | 50/60Hz |
| Output Current | 16A/24A/32A/40A/48A adjustable |
| Over Temperature Protection | ≥ 95°C |
| Rated Residual Operating Current | CCID20 |
| Charging Start Mode | Plug and play,RFID,APP |
| Operating Temperature | -30℃~+50°C |
| Storage Temperature | -40℃~+85°C |
| Relative Humidity | 5%~95% No condensation |
| Life Time Of Connector | >10000 times |
| Mean Time Between Failure | MTBF≥30000h |
| APP/Communication | Support/WIFI,BLE,4G Optional |
| Cable Length | 5 meters(Customizable) |
| Weight | 1.8kG (cable not included) |
| Color | White/Black/Dark Grey |
| Power Plug | US(Standard) |
| Connector Type | IEC 62196-2 Type 2 |
| Maximum Altitude | 2000m |
| Degree Of Protection | Charging Connector IP54,Host IP66/IK10 |
| Host Dimension | 296*192*77(mm) |
| Wiring method | Enter and out at the bottom |
