● Type 2 cable/Type 2 socket
● APP Charging Scheduling
● Start Modes: RFlD/Plug&Play/APP
● Multi communications(WiFi/4G/BLE)
● Charging Connector IP54,Host IP66/IK10
● 30mA Type A +6mA DC residual current protection
| PERFORMANCE SPECIFICATIONS | |
| Model | FF-AC3112USH-LJK |
| Standard | US |
| Power | 11.5kW |
| Input/Output Voltage | 208~240VAC/208~240VAC |
| Input Frequency | 50/60Hz |
| Output Current | 16A/24A/32A/40A/48A adiustable |
| Rated Residual Operating Current | CCID20 |
| Over Temperature Protection | ≥95℃ |
| Mean Time Between Failure | MTBF≥30000h |
| Charging start Mode | Plug and Play, RFID, APP |
| APp/Communication | Support/WIFl, BLE, 4G Optional |
| Relative Humidity | 5%~95% No condensation |
| Maximum Altitude | 2000m |
| life Time Of Connector | ≥10000 times |
| Test Specifications | GB/T 34657.1-2015 |
| Operating /Storage Temperature | -30℃C~+55°C |
| Storage Temperature | -40℃~+85°C |
| Cable Length | 5 meters(Customizable) |
| Wring Method | Enter and out at the bottom |
| Connector Type | IEC 62196-2 Type 2 |
| Power Plug | US(standard) |
| Color | White/Black/Dark Grey |
| Host Dimension | 204*364*90mm |
| Degree Of Protection | Charging Connector lP54,Host IP66/IK10 |
